Twin Screw PP Strap Production Machine with 230-260Kg/h Capacity for Sandwich Straps Using PP Recycled Material

صورة كبيرة : Twin Screw PP Strap Production Machine with 230-260Kg/h Capacity for Sandwich Straps Using PP Recycled Material

تفاصيل المنتج:

مكان المنشأ:	الصين
اسم العلامة التجارية:	JIATUO CHINA
إصدار الشهادات:	ISO CE
رقم الموديل:	جي تي بي بي-110/75
وثيقة:	PP strap production line-A.pdf

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 مجموعة
الأسعار:	قابل للتفاوض
تفاصيل التغليف:	فيلم بلاستيكي
وقت التسليم:	50-60 يوم
شروط الدفع:	الاعتماد المستندي، تي/تي
القدرة على العرض:	50set/شهر

اتصل

Twin Screw PP Strap Production Machine with 230-260Kg/h Capacity for Sandwich Straps Using PP Recycled Material

وصف

عدد الحزام:	2/4/6/8/10/12 حزام	سمك (مم):	0.3-1.2 ملم
عرض:	5-19 ملم	القدرة الإنتاجية:	230-260 كجم/ساعة
مغير الشاشة:	تلقائي أو يدوي	نموذج المسمار:	110/75 ملم
مواد الإنتاج:	مادة البولي بروبيلين المعاد تدويرها	تصميم المسمار:	برغي مزدوج 110 مم 75 مم
محرك:	جوغاو	العاكس:	INVT
أنظمة التحكم:	نظام التحكم الصيني/اللغة الإنجليزية PLC	ضمان:	1 سنة
الإنتاج النهائي:	حزام التعبئة المغزول PP (قالبان لحزامين)	إجمالي قوة التثبيت:	80 كيلو وات (استهلاك الطاقة الفعلي 40-50%)
طلب:	السيراميك والأثاث والكرتون
إبراز:	Twin screw PP strap machine , PP strap production machine 230-260Kg/h , PP recycled material strap machine

Twin Screw PP Strap Production Machine Make Sandwich Strap Use For Ceramics Furniture

Twin Screw PP Strap Production Machine Make Sandwich Strap Use For Ceramics Furniture

PP Sandwich Belt Production Machine Description

The PP sandwich belt making machine consists of a main host and auxiliary units, equipped with 2 feeders and 2 material barrels; other components remain the same.

Sandwich belts are widely used in ceramic factories. They adopt a composite structure: high-quality material for the outer layer and recycled material for the inner core.

Our twin-screw PP strap making machine features versatile functions. It can produce both single-layer and double-layer straps to meet diverse customer requirements.

General Parameters of PP Strap Making Machine

Model	Output	Strap Quantity	Strap Width	Raw Material
JT-PP90	100-120Kg/h	2 straps	5-19 mm	100% PP recycled material & new raw material
JT-PP110	230-260Kg/h	4 straps	5-19 mm
JT-PP125	350-380Kg/h	6 straps	5-19 mm

Process Flow of PP Packing Belt Production Line

Feeding
Mixing material
Pre-drying
Melting and measuring extrusion
Embryo (belt embryo) cooling and forming
Oven pre-heating
Primary stretching
Secondary stretching
Embossing
Oven tempering and setting
Cooling
Finished product winding

Tip: If you choose printing, you can print first and then emboss in step eight.

Components of Polypropylene Strap Production Machine

Main machine and auxiliary machine: Twin-screw extruded sandwich strapping band, higher tensile strength and more cost-effective.
Mold: Independent designed die head, manufactured by large CNC machining centers. Higher precision and more uniform extrusion effect.
Five roll wheel: The five rollers are hard chrome plated, featuring higher hardness and longer service life.
Double station winder: Easy operation and higher winding efficiency.

Frequently Asked Questions

Q: What voltage is applicable?

A: Customizable according to different countries, such as 380V/50Hz, 415V/50Hz, 220V/60Hz, etc.

Q: Do you provide installation and training?

A: Yes, we provide overseas installation, commissioning, and operator training.

Q: Can 100% recycled material be used?

A: Yes, but the strength will decrease. It is recommended to mix with new material or use for inner layer of sandwich strap.
