تفاصيل المنتج:
|
| اسم المنتج: | خط حزام الحيوانات الأليفة | مادة: | مادة رقائق زجاجة PET / مادة إعادة تدوير PET |
|---|---|---|---|
| مزود الطاقة: | 380 فولت/50 هرتز/220 فولت/60 هرتز ثلاث مراحل | الأتمتة: | شاشة كمبيوتر تعمل باللمس PLC |
| فلتر إزالة الزيت وإزالة الغبار: | 1 مجموعة | المحرك الرئيسي: | 37 كيلو واط (جوغاو) |
| لف أنيق: | نعم | برج ما قبل التجفيف: | 5000L |
| القدرة الإنتاجية: | 220-250 كجم/ساعة | عرض: | 9-32mm |
| سماكة: | 0.4-1.2 ملم | سرعة الخط: | > 260 م/دقيقة |
| إبراز: | 950kg PET Strap Extrusion Line,SGS Certification PET Strap Extrusion Line |
||
| Item | Product name | Q’ty |
| 1 | Materials | PET raw material or 100% PET bottle flakes recycled |
| 2 | Product | PET output 4straps making machine |
| 3 | Capacity | 450-500kg/h |
| 4 | Total install power | 300kw, (actual power consumption is 50-55%) |
| 5 | Strap width | 9 mm-32 mm |
| 6 | Thickness | 0.4 mm-1.2 mm |
| 7 | Manpower | 2person/shift |
| 8 | Workshop required | L (58m) ×W (2m) ×H (8m) |
| 9 | Power source | 380V, 50Hz, 3Phase (according to customer requirement) |
| 10 | Electric components | Schneider |
| 11 | Inverter | INVT |
| 12 | Switches | Taiwan Fotek |
| 13 | Motor power | Gugao |
| 14 | Gearbox | GUOMAO |
| 15 | Warranty period | 12 months |
1. Feeding to → 2.mixing raw materials→ 3. pre-drying→ 4. Vacuum dehumidification of raw materials→ 5. raw materials melting extrusion→ 6. material embryo expression(with embryo) cooling molding → 7.preheat the oven→ 8. firstly stretching → 9. secondly streching → 10. embossing → 11. tempering oven→ 12. cooling → 13.winding to finished product
Advantags of PET strap making machine
1. process 100% recycled PET bottle flakes.
2. even plasticization and stable extrusion with PLC automatic control for the whole line.
3. as per different requirements, changing a coating materials for making strap has better and special function. For example, the strap for packing cotton can be from enhancing the breaking strength and joint strength when welding strap.
4. Melt filter with two pistons with air venting design amd back flushing.
5. Production line just need 1-2 workers ,suit to 24 hours moving per day.
6. Finished product: width: 9-32 mm, thickness: 0.4-1.2mm.
FAQ
1.Are you manufacturer or trading company?
We are manufacturer.
2.Why choose us?
We have 30 years experience for producing machine.We can arrange for you to visit our local customer's factory.
3.Delivery time: 20~30 days.
4.Payment terms:
30% of total amount should be paid by T/T as down payment, the balance (70% of total amount) should be paid before delivery by T/T
or irrevocable L/C(at sight).
