تفاصيل المنتج:
|
| عرض حزام: | 9-32mm | قوة: | 55 كيلو واط |
|---|---|---|---|
| حجم أنبوب الورق: | تباطؤ عالي السرعة | قطر الورق الأساسي: | Ø406 * 150 ملم |
| العاكس المضيف: | 55 كيلو واط (إينفت) | سعة: | 300-350 كجم/ساعة |
| وزن: | 21000 كجم | سرعة: | 120-260 م/دقيقة |
| مادة خام: | رقائق زجاجة الحيوانات الأليفة | الجهد االكهربى: | 380 فولت/50 هرتز (قابل للتخصيص) |
| إبراز: | PET plastic steel strip production line,Servo automatic winding machine |
||
Features of PET automatic wrapping machine:
Application:PET plastic steel belt automatic winding machine is a servo winding machine that can automatically wind, rewind, cut and change rolls. Once the application is started, the system will work independently.
Width: 9-32mm.
Dehumidifier----A rotary honeycomb dehumidification and drying system dries the raw materials. A dew point of -50℃ ensures that the moisture content of the raw materials is ≤50PPM, while also having a solid-phase condensation and thickening effect.
Stretching System----- The equipment employs a unique double stretching process, resulting in superior strapping rigidity, stable width, and improved tensile strength.
Heating System------- A unique oven-circulating heating system utilizes a reciprocating winding method to fully leverage heat energy and significantly reduce power consumption.
|
Model |
PET Plastic Extrusion Machine |
| Materials | PET raw material or 100% PET bottle flakes recycled |
|
Number of Mandrels |
1~2 |
|
Winding speed |
50 – 250 m/min |
| Strap Width | 9-32mm |
| Paper core diameter | Ø406*150mm |
|
Maximum pick up speed |
350 m/min |
| Strap Thickness | 0.6-1.2mm |
| Control System | PLC Computer Touch Screen |
|
Maximum package diameter |
820 mm |
Basic equipment
Dancer control for controlling of a constant strap tension and winding speed, Dual servo motor
Precise, electronically controlled 2 or 3 or spiral point laying with minimal strap bend of the straps
Pneumatic mandrels for fast bobbin changes
Two measurement modes: weight and meter
Our PET plastic steel belt equipment provides comprehensive technical support and services. We have an experienced technical team that can quickly provide a variety of services, including:
Pre-sales:
1. Layout of PET plastic steel belt equipment.
2. Analysis of finished product manufacturing costs of PET plastic steel belt equipment.
3. Analysis of raw materials used in PET plastic steel belt equipment.
After-sales service:
1. Waterway diagram, circuit diagram, pipeline connection drawings, etc. of PET plastic steel belt equipment.
2. Installation, commissioning and training of PET plastic steel belt equipment.
3. Maintenance service of PET plastic steel belt equipment.
4. Regular maintenance and repair
5. Fault diagnosis
6. Software update and upgrade
7. Spare parts and accessories
8. Training and technical consultation
Q: What is the voltage of the PET plastic steel belt equipment?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt equipment?
A: Different models have different extrusion capacities, ranging from 150-600KG/H
Q: Where does the PET plastic steel belt equipment come from?
A: China.
Q: What are the certifications for PET plastic steel belt equipment?
A: ISO CEO certification.
Q: What is the minimum order quantity for PET plastic steel belt equipment?
A: 1 set
Q: What is the weight of the PET plastic steel belt equipment?
20T, 40GP container * 3PCS
