تفاصيل المنتج:
|
| اسم المنتج: | خط حزام الحيوانات الأليفة | مادة: | مادة رقائق زجاجة PET / مادة إعادة تدوير PET |
|---|---|---|---|
| مزود الطاقة: | 380 فولت/50 هرتز/220 فولت/60 هرتز ثلاث مراحل | الأتمتة: | شاشة كمبيوتر تعمل باللمس PLC |
| فلتر إزالة الزيت وإزالة الغبار: | 1 مجموعة | المحرك الرئيسي: | 37 كيلو واط (جوغاو) |
| لف أنيق: | نعم | برج ما قبل التجفيف: | 5000L |
| القدرة الإنتاجية: | 220-250 كجم/ساعة | عرض: | 9-32mm |
| سماكة: | 0.4-1.2 ملم | سرعة الخط: | > 260 م/دقيقة |
| إبراز: | pet belt making machines,Customized Color PET Belt Making Machine,Double Station Winder Belt Making Machine |
||
| Screw model | 90 (Single screw or double screw) |
| Number of strap | 2 straps |
| Width | 9-32mm |
| Thickness | 0.3-1.2mm |
| Screen changer | Automatic/Manual |
| Control system | PLC control(Chinese and English) |
| Production capacity | 220-250kg/H |
| Reducer Brand | GUOMAO |
| Motor Brand | Gugao |
| Pull of finial product | 150kg-900kg |
| Line speed | More than 160m/min |
| Material | PET crushed material/bottle flake material |
The features of PET packing belt production line
Diversity of raw materials: The raw materials used in this production line include PE, PP, PET, etc. these raw materials have good plasticity and processability, suitable for large-scale production.
Environmental protection: The PET polyester strapping belt produced by PET packing belt production line is a kind of recyclable environmental protection material, has good weather resistance, is stable in the temperature range of -50ºC to 100ºC, is suitable for various environmental conditions.
Efficient production: we have 2/3/4/6/8 strips at the same time, available for different production needs of customers to make a choice, and the production capacity is also very high, the output of 2 strips per hour can reach 220-250kg/H.
1. feeding to → 2.mixing raw materials→ 3. ingredients are vacuum dehumidification prebake→ 4. Vacuum dehumidification of raw materials→ 5. raw materials melting extrusion→ 6. material embryo expression(with embryo) cooling molding → 7.preheat the oven→ 8. firstly stretching → 9. secondly streching → 10. embossing → 11. tempering oven→ 12. cooling → 13.winding to finished product.
