Invt Inverter Polyester PET Strap Making Machine 90mm Single Screw 210-230kg/h PET Packing Strap Machine w/ 9mm-32mm Wid

صورة كبيرة : Invt Inverter Polyester PET Strap Making Machine 90mm Single Screw 210-230kg/h PET Packing Strap Machine w/ 9mm-32mm Wid

تفاصيل المنتج:

مكان المنشأ:	شنتشن الصين
اسم العلامة التجارية:	JIATUO CHINA
إصدار الشهادات:	CE ISO
رقم الموديل:	جتبيت-90

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 مجموعة
الأسعار:	قابل للتفاوض
تفاصيل التغليف:	فيلم بلاستيكي
وقت التسليم:	50-60DAYS للتفاوض
شروط الدفع:	الاعتماد المستندي، تي/تي

اتصل

Invt Inverter Polyester PET Strap Making Machine 90mm Single Screw 210-230kg/h PET Packing Strap Machine w/ 9mm-32mm Wid

وصف

طلب:	حزام التعبئة	تصميم المسمار:	برغي واحد
قطر المسمار (مم):	90 ملم	مكان المنشأ:	قوانغدونغ شنتشن الصين
إجمالي قوة التثبيت:	250 كيلو وات (استهلاك الطاقة الفعلي 150-160%)	سعة:	210-230 كجم/ساعة
فيديو التفتيش الصادر:	متاح	ضمان:	1 سنة
اسم:	آلة البثق	عرض:	9-32mm
سماكة:	0.6-1.2	مواد:	رقائق / خردة من مادة البولي إيثيلين تيريفثالات معاد تدويرها بنسبة 100٪
الصناعات المعمول بها:	محلات مواد البناء ومصنع التصنيع والآلات	طريقة التبريد:	إعادة تدوير المياه
إبراز:	PET strap making machine 90mm single screw , PET packing strap machine 210-230kg/h , PET strap extrusion line 9mm-32mm width

Inverter Invt PET Polyester Packing Strap Making Machine 90mm Single-Screw

General description of PET strap making machine

1	Materials	PET raw material or 100% PET bottle flakes recycled
2	Product	PET output 3straps making machine
3	Capacity	210-230kg/h
4	Total install power	250kw, (actual power consumption is 150-160%)
5	Strap width	9 mm-32 mm
6	Thickness	0.6 mm-1.2 mm
7	Manpower	2person/shift
8	Workshop required	L (55m) ×W (2m) ×H (7m)
9	Cooling water	≤20℃,≥0.3Mpa, 5-8Ton/hr
10	Compressed air	0.5-0.8Mpa
11	Power source	380V, 50Hz, 3Phase (according to customer requirement)
12	Electric components	Schneider
13	Inverter	INVT
14	Switches	Taiwan FOTEK
15	Motor power	Simens
16	Bearing	TR

Invt Inverter Polyester PET Strap Making Machine 90mm Single Screw 210-230kg/h PET Packing Strap Machine w/ 9mm-32mm Wid 0

Process flow of PET packaging belt production line:

① feeding→② mixing raw materials→③ raw material pre-drying→④ vacuum dehumidification of raw materials→⑤ raw materials melting extrusion→⑥ material embryo expression(with embryo) cooling molding→⑦oven preheating→⑧first stretching→⑨second stretching→⑩embossing→⑪ oven tempering to set the shape→⑫ cooling → ⑬winding(finished product)

Features of PET packing strap production line

Better tensile strength: the PET strap production line has the tensile strength of the steel belt, and the ductility is good, and the anti-impact performance is better. It is not easy to break, and it can ensure the safety of product transportation.
Small extension: Although PET strap is one kind of plastics, its extension of change is very small, its elongation is only 1/ 6 of polypropylene, it can maintain tension force, after the packing make the expansion no longer change.
Strong temperature resistance: the experiment proved that the melting point of PET packing belt at about 260 ℃, can be used under the environment of 120 ℃ for a long time not to distort,it has a good stability.
Good economic benefit: the density of PET packaging belt is 1.30 ~ 1.38 g/cm3, which is only 1/6 of the steel belt density (7.8 g/cm3), which is equivalent to the length of the 6-ton steel belt, and the price of the same unit length is relatively low.
Environmentally friendly: the steel belt will rust due to exposure to the air, and the rust is highly permeable to the packaging. PET packing tape is beautiful and not rusted, but avoid unnecessary worry. It can also be recycled.
Good flexibility and safe operation: the PET packing strip has no sharp edge with steel belt, it will not scratch the package, and it will not hurt the hand. You don't need a special tool when you cut it, even if it's tight, it doesn't hurt when you cut it.
High quality packaging ideal products: PET packaging with all kinds of bright colors, shiny, high quality, the most ideal packaging products of high-end packaging

Machine packaging & Delivery

Our services

------Before order: We will provide relevant information on various technology and business consulted by customers. If clients want to visit our company, we will offer all they need for convenience.

------During order: company designs groundsill installation chart for water, electricity and gas of equipment basing on real condition and customers’ requirements and provides detail order list and matching manufacturer for reference for customer.

After equipment arrival, our service personnel will arrive at posted locale for installation, debugging, training and technology transfer till customers can operate independently and manufactures eligible product. Service personnel have to arrive at customer’s locale in time when we provide service for client again.

------ After order: we will offer 12months after sales service freely, but our service will be life-long. if some parts are broken, we will send them by express, air or ship as soon as we can.
