تفاصيل المنتج:
|
| نوع المنتج: | خط بثق حزام التعبئة PP | مادة خام: | حبيبات المواد الخام من مادة البولي بروبيلين PP، الكريات المعاد تدويرها |
|---|---|---|---|
| تصميم المسمار: | من 1 إلى 4 | نوع المعالجة: | آلة البثق |
| سعة: | 200 كجم/ساعة | قوة: | 100 كيلو واط |
| نوع مدفوعة: | كهربائي | طلب: | حزام التعبئة والتغليف |
| الأتمتة: | تلقائي | ضمان: | 1 سنة |
| إبراز: | PP strapping machine with 100-300m/min speed,PP plastic strapping production line,PP strap making machine with warranty |
||
Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed
PRODUCT DESCRIPTION
Extrusion----Extrusion capacity can be customized according to customer requirements, and can produce 2-12 strips.
Oven-----Energy-saving and environmentally friendly, constant temperature oven, high output, low power consumption.
Winding machine-----Can be equipped with semi-automatic winding machine & fully automatic winding machine according to customer requirements
Polypropylene strapping is the most economical of all strapping material due to it's light weight and versatility.it is available in a wide variety of sizes and gauges and offers the greatest elongation of any strapping type,along with good initial recovery characteristics.polypropylene can be heat sealed with joint efficiency of 70 to 80%.
Name: PP 1 to 4 strapping production line
Model number: JTPP-110
Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials
Number of screws: 1 Screw
Number of extruded belts: 4
Width range: 5-19mm
Thickness range: 0.4-1.2mm
Production capacity: 200-250kg/h
Installation size: L38*W2.0*H4.0(m)
| Model No. | Screw Size | No. of strap | Capacity | Total Power | Width | Thickness | Installation Dimensions |
| JTPP-90 | 2800mm | 2 | 100kg/h | 80kw | 5-19mm | 0.4-1.2mm | 30*2.0*4.0M |
| JTPP-100 | 2800mm | 3 | 150kg/h | 90kw | 5-19mm | 0.4-1.2mm | 30*2.2*4.0M |
| JTPP-110 | 3300mm | 4 | 200kg/h | 100kw | 5-19mm | 0.4-1.2mm | 38*2.0*4.0M |
| JTPP-125 | 3700mm | 6 | 200-250kg/h | 110kw | 5-19mm | 0.4-1.2mm | 40*2.0*4.0M |
The process flow of PP Packing Strap Belt Making Machine:
Vacuum feeding → Dryer → Extruding system → High speed Net exchanging system → Mould → Water cooling system →
Traction rollers → Stretch oven 1 → Tensile unit→ Embossing unit → Tensile unit→ Double winder
Features of PP strapping equipment
High degree of automation----- reduce manual intervention, improve efficiency, PLC control, easy debugging.
High production efficiency----- continuous production, large output, 24-hour non-stop production.
Stable product quality----- automated control ensures consistency of extrusion specifications, suitable for high-end strapping machines.
Company advantages:
Our company has more than 30 years of experience in strapping equipment manufacturing in China. We have a professional R&D team, sales team, production plant, imported processing equipment from Germany, and technical personnel often go abroad for further study and learning. We have more than 50 patented products. In China's strapping packaging industry, our company has a good reputation, advanced technology, and high-end products, and always ranks first. We can provide customers with better equipment and produce higher-end products.
Currently: We have our own
PP strapping production factory: 1 PCS
PET strapping production factory: 2, PCS
PP PET strapping equipment manufacturing factory: 1PCS
We are fully aware of the formula ratio of various raw materials, the equipment ratio of various parameters, and the technical parameters of the strapping tapes required by our customers during the production process.
