تفاصيل المنتج:
|
| سرعة الخط: | 250 م / دقيقة | مادة: | حيوان أليف |
|---|---|---|---|
| مزود الطاقة: | 380 فولت/50 هرتز | الأتمتة: | تلقائي |
| قدرة البثق: | 50-600 كجم/ساعة | سمك حزام: | 0.4-1.2 ملم |
| إجمالي الطاقة: | 120 كيلو واط | طلب: | الورقة والحزام والأنابيب وشريط التغليف والشريط والحزام |
| إبراز: | PET strap extrusion machinery 250m/min,PET strap extrusion line 50-600kg/h,PET strap extrusion equipment 380V/50Hz |
||
12mm Width Plastic PET Packing Strap Machine Extruder Production Line
PRODUCT DESCRIPTION
PET strap, also known as plastic steel band, which is used in place of steel on the world of a new environmentally friendly packaging materials, the development of new materials in recent years the cost of success and a substantial decline, have been widely used in the steel industry, chemical fiber industry, aluminum ingots, paper, brick kiln industry, screw industry, tobacco industry, electronics, textiles and wood, etc.; It is replaced by a new high-strength steel strapping, is the world’s most widely used for steel products with high strength.
PET Strap Production Line Machine List
| NO. | Item | Specification |
| 1 | Power | According to customer's factory voltage |
| 2 | Material | PET raw material or 100% PET bottle flakes recycled |
| 3 | Capacity |
PETJT90:200kg/h PETJT100:250kg/h PETJT125:350kg/h |
| 4 | Product size |
Width:9-32mm Thickness:0.6-12mm |
| 6 | Mid-height of extruder | 7000mm |
| 7 | Installation power |
PETJT90:200KW PETJT100:250KW PETJT125:300KW |
| 8 | Humidity | <85% |
| 9 | Temperature | 0-40 degree |
| 10 | Cooling tower capacity | 30T/H or 50T/H |
| 11 | Installation Dimensions |
PETJT90:45*2.0*7.0M PETJT100:45*2.0*7.0M PETJT125:60*3.0*8.0M |
| 12 | Product color | Green/Black/Pink/Yellow |
| 13 | Factory dimension |
35m*(3~6)m*(4~6)m 45m*(3~6)m*(4~6)m If your factory not big enough,please contact with us,our engineer can according to your size to design |
Features of PET packing strap production line:
1. The extruder adopts PET special screw with unique parameter design. The screw has a unique separation and mixing effect, which ensures the uniform plasticization of raw materials. It has large extrusion volume, good plasticization, high hardness and high wear resistance. Etc.
2. The three-dimensional folded super-large area filter device, the unfolded area of the filter screen is 30 times larger than that of the traditional flat filter screen; the filtering mesh number can reach 80 meshes, and the unique screen changing device greatly reduces the screen changing time and improves the work efficiency.
3. Using the rotary honeycomb dehumidification and drying system to dry the raw materials, the dew point of -50 °C ensures that the moisture content of the raw materials is ≤50PPM, and it has the effect of solid-phase polycondensation and viscosity enhancement.
4. The equipment adopts a unique two-stretching process, which has good rigidity and stable width, and improves the tensile strength of the finished product.
5. High-precision parts make the product molding quality stable, and the width and thickness fluctuations are far smaller than the national standard;
6. The unique oven circulation heating system adopts reciprocating winding method inside, making full use of thermal energy to greatly reduce power loss.
7. The unique circulating cooling system and multiple sets of shaping belt guide rollers make the packaging belt cooling and shrinking and shaping more fully, the product is more stable and the size is more accurate.
8. Five-roller traction system, stable traction, smooth equipment operation, reduced failure rate, and reduced maintenance costs by 60%.
9. High-precision special embossing and pressing device, adjustable pressure, the embossing wheel can be synchronized up and down, the embossing is clear and beautiful, and the product quality is comparable to that of European, American, Japanese and Korean packing belts.
10. Constant force winding system, unique design parameters, in line with high output, excellent winding effect, flat and beautiful on both sides.
11. The rewinder adopts a double-station rewinding device, which is easy to operate and easy to change.
12. It can all be produced with 100% bottle flakes, and the quality of the finished product can be compared with brand new materials.
DETAILS ABOUT PET STRAP MAKING MACHINE
1. Components of pp pet packing belt machinery:
PET Strap Production Line consists of dehumidifying and crystallizing system, extruder, screen changer, mold, oven, haul-off, and winder, etc.
2. Production Process of PET Machinery
Material→ Dehumidifying and Crystallizing → Extruding → Mold → Cooling → Haul-off →Oven Heating →Pre-heating → Drawing and Stretching →Drawing and Stretching → Embossing →Hot Forming → Drawing → Winding
3. Application
With 100% bottle flakes recycled material, to produce various specifications of PET strap. It has been widely used in steel, chemical industry, aluminum, paper making, brick kiln, tobacco, electronics and textile and timber industries.
