GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer

صورة كبيرة : GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer

تفاصيل المنتج:

مكان المنشأ:	شنتشن، الصين
اسم العلامة التجارية:	JIATUO
إصدار الشهادات:	CE, ISO
رقم الموديل:	جي تي بي بي-110
وثيقة:	parameter details of PP Str...ne.pdf

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 مجموعة
الأسعار:	قابل للتفاوض
تفاصيل التغليف:	فيلم بلاستيكي أو حزمة قياسية أخرى للشحن البحري
وقت التسليم:	50 ~ 55 يوم عمل
شروط الدفع:	L/C ، D/A ، T/T ، Western Union ، Moneygram
القدرة على العرض:	50set/شهر

اتصل

GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer

وصف

نوع المنتج:	خط بثق حزام التعبئة PP	مادة خام:	حبيبات المواد الخام من مادة البولي بروبيلين PP، الكريات المعاد تدويرها
تصميم المسمار:	من 1 إلى 4	نوع المعالجة:	آلة البثق
سعة:	200 كجم/ساعة	قوة:	100 كيلو واط
نوع مدفوعة:	كهربائي	طلب:	حزام التعبئة والتغليف
الأتمتة:	تلقائي	ضمان:	1 سنة
إبراز:	Polypropylene Plastic PP Strap Making Machine , 100 KW PP Strap Making Machine , Plastic PP Strap Band Extruding Line

https://www.strap-makingmachine.com/sale-52050456-5-19mm-single-double-screw-pp-packing-belt-making-line-with-high-strength-and-length.html

GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer

PRODUCT DESCRIPTION OF PP STRAP MAKING MACHINE

Polypropylene strapping is the most economical of all strapping material due to it's light weight and versatility.it is available in a wide variety of sizes and gauges and offers the greatest elongation of any strapping type,along with good initial recovery characteristics.polypropylene can be heat sealed with joint efficiency of 70 to 80%.

PP strapping production line 1 to 4 product parameters:

Name: PP 1 to 4 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 4

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 200kg/h

Installation size: L38*W2.0*H4.0(m)

Model No.	Screw Size	No. of strap	Capacity	Total Power	Width Range	Thickness Range	Installation Dimensions
JTPP-90	2800mm	2	100kg/h	80kw	5-19mm	0.4-1.2mm	302.04.0M
JTPP-100	2800mm	3	150kg/h	90kw	5-19mm	0.4-1.2mm	302.24.0M
JTPP-110	3300mm	4	200kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M
JTPP-110	3300mm	6	130kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M

The process flow of PP Packing Strap Belt Making Machine

Vacuum feeding → Dryer → Extruding system → High speed Net exchanging system → Mould → Water cooling system →

Traction rollers → Stretch oven 1 → Tensile unit→ Embossing unit → Tensile unit→ Double winder

GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer 0

Plastic Strapping

Plastic strappping materials are made from Polyester,Polypropylene and are available in a variety of strengths,

styles,and finishes.Unlike steel strapping,elongation and recovery are a key factor for deciding which type of

plastic strap to use.

Polypropylene Strapping

Polypropylene strapping is an economical strapping material compared to other materials.it's designed for light to

medium duty unitizing,palletizing and bundling.Consistent pressure to polypropylene strapping can result in

unrecoverable dead stretch and inability to return to its original length

Advantages of PP strapping production line

PP raw materials do not need to separate the dry and water treatment . There are automatic circulation on preheating and

drying that save a large number of equipment investment and reduce the production cost by 30%;

Utilizing the retrieving bottle slice as raw materials that reducing the cost to a great extent;

With the multi-purpose machine, produce the PP PET straps in different specifications directly and don not need to change the mould head;

Comparing with new polyester slice, the transparency of products is just the same, but the tensile strength and shock

resistance are up to the international grade;

Low Energy consumption, but high production capability;

Easy to operate, save the manpower and two persons for one production line on average

GUOMAO Motor Plastic PP Strap Making Machine 100 KW With Non-Stop Screen Changer 2
