5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

Name: 5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H
Brand: SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD
SKU: جي تي بي بي-110
Price: 34,500.00 USD
Availability: InStock

جميع المنتجات

PP Strap Making Machine
(651)

PET Strap Making Machine
(483)

PP Strap Band Extrusion Line
(262)

PET Strap Extrusion Line
(246)

Strapping Band Winding Machine
(151)

Automatic Baling Machine
(161)

PET Packaging Strap
(374)

PP Packing Belt
(295)

Packing Belt Making Machine
(35)

Packaging Tape Printing Machine
(26)

Plastic Film Embossing Machine
(7)

Tensile Testing Machine
(10)

Plastic Extrusion Screen Changer
(8)

Extrusion Machine Parts
(16)

Handheld Strap Baling Machine
(21)

Pneumatic Strapping Machine
(11)

أفضل المنتجات

5-15mm PP Strapping Production Line

Plastic PP Packing Strap Production Line

380kg/H PP Strap Making Machine Single Screw

شهادة

الصين SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD الشهادات

زبون مراجعة

Well received the PET strap making machine today, it's easy for installation and operation.

—— Ahmed from Sudan

Jiatuo Machinery PP Tape Making Machine delivers stable and reliable performance. Current customer feedback indicates excellent product quality from the new machine, with orders continuously increas

—— Pakistan - Customer Testimonia

Since using JIATUO strapping line, our production efficiency has increased dramatically and the equipment is running very stably!

—— Avinash from India

Excellent cooperation with Jiatuo Machinery, and thanks for Zoey's fast service. I am going to buy another one PP making machine!!!

—— Mustafa Koçak from Turkey

Indian customer feedback: Purchased PP strapping machine, embossing is clear, and cooperation was pleasant.

—— India---Customer Testimonials

High production capability and low energy consumption, which can help me to make lots of money!!

—— Kashan from Pakistan

This is the second PP machine I ordered, the output is very high, the energy consumption is low, which greatly saves my production cost, thank you very much for Arey's patient guidance and service!

—— Hasseb from Columbia

Indonesia---Customer Testimonial Customer feedback on purchasing Jia Tuo's PP strapping machine: High production quality, saves on electricity costs. Collaboration with Lily was very pleasant, with clear communication on details and excellent service.Reorder 300 rolls of premium PP belt.

—— Indonesia---Customer Testimoni

JIATUO's technical team is very professional, door to door installation of our machine, a few days is exactly stable operation, thank you very much!

—— Farzed from Turkey

Apart from routine maintenance, it has rarely experienced any malfunctions, ensuring the continuous operation of our production line—this is what gives us the greatest peace of mind.

—— Baslem from Egypt

PET strapping is of high quality, strong, and does not crack.

—— Asif from Argentina

Jiatuo's PET strap is of extremely high quality, which has greatly expanded our market in Togo. We are also very grateful to Arey and the technical team of Jiatuo for their assistance.

—— Raphael from Togo

It is perfect and flawless of PET strap making machine. I am very grateful for the technical support provided by the Jiatuo team.

—— Pierre from Saudi Arabia

The PP strapping machine offers stable performance, low failure rate, and high production output.

—— Saudi Arabia saidali

JIATUO's PET strap making machine A truly reliable piece of equipment that boosts productivity! good!

—— Mohamed from Egypt

The PET strapping is of good quality, sells very well locally, and the customers are very satisfied.

—— Sami from Saudi Arabia,

The PP strapping belt is of good quality, very popular locally, and customers are very satisfied. The price is reasonable

—— Mhammed from India

ابن دردش الآن

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

صورة كبيرة : 5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

تفاصيل المنتج:

مكان المنشأ:	شنتشن، الصين
اسم العلامة التجارية:	JIATUO
إصدار الشهادات:	CE, ISO
رقم الموديل:	جي تي بي بي-110

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 مجموعة
الأسعار:	قابل للتفاوض
تفاصيل التغليف:	فيلم بلاستيكي أو حزمة قياسية أخرى للشحن البحري
وقت التسليم:	50 ~ 55 يوم عمل
شروط الدفع:	L/C ، D/A ، T/T ، Western Union ، Moneygram
القدرة على العرض:	50set/شهر

اتصل

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

وصف

نوع المنتج:	خط بثق حزام التعبئة PP	مادة خام:	حبيبات المواد الخام من مادة البولي بروبيلين PP، الكريات المعاد تدويرها
تصميم المسمار:	من 1 إلى 6	نوع المعالجة:	آلة البثق
سعة:	130 كجم / ساعة	قوة:	100 كيلو واط
نوع مدفوعة:	كهربائي	طلب:	حزام التعبئة والتغليف
الأتمتة:	تلقائي	ضمان:	1 سنة
إبراز:	19mm Width PP Strap Making Machine , 19mm Width pp strap extrusion line , pp strap extrusion line 200kg/H

5-19mm Width PP Strap Making Machine Band Extruder 200kg/h Max Capacity

PRODUCT DESCRIPTION

PP strapping production line 1 to 6 product parameters:

Name: PP 1 to 6 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 6

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 130kg/h

Installation size: L38*W2.0*H4.0(m)

Model No.	Screw Size	No. of strap	Capacity	Total Power	Width Range	Thickness Range	Installation Dimensions
JTPP-90	2800mm	2	100kg/h	80kw	5-19mm	0.4-1.2mm	302.04.0M
JTPP-100	2800mm	3	150kg/h	90kw	5-19mm	0.4-1.2mm	302.24.0M
JTPP-110	3300mm	4	200kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M
JTPP-110	3300mm	6	130kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M

The process flow of PP Packing Strap Belt Making Machine:

Vacuum feeding → Dryer → Extruding system → High speed Net exchanging system → Mould → Water cooling system →

Traction rollers → Stretch oven 1 → Tensile unit→ Embossing unit → Tensile unit→ Double winder

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H 0

Plastic Strapping

Plastic strappping materials are made from Polyester,Polypropylene and are available in a variety of strengths,

styles,and finishes.Unlike steel strapping,elongation and recovery are a key factor for deciding which type of

plastic strap to use.

Polypropylene Strapping

Polypropylene strapping is an economical strapping material compared to other materials.it's designed for light to

medium duty unitizing,palletizing and bundling.Consistent pressure to polypropylene strapping can result in

unrecoverable dead stretch and inability to return to its original length

Features of PP strapping production line:

1. It is suitable for all levels of recycled plastic particles, and produces sandwich belts and PP environmentally friendly packing belts;

2. It can be used to directly produce manual packing belts;

3. It can also be directly processed into hand-use, machine-use, printing packing tape, ultra-wide, ultra-thin, ultra-narrow, transparent, dyeing, and printing PP packing tape;

4. It is currently the most cost-effective and competitive product on the market, and is popular among small and medium-sized investors;

5. It can produce all kinds of manual belts, machine-use PP packing belts and export belts.

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H 2
